TS-207 – Military-grade IP65 Fanless Box PC by Advantech

The Advantech TS-207 is a military-grade fanless IP65 box PC designed for transportation and outdoor AIoT applications. Powered by 11th Gen Intel Core U-Series processors, it features four M12 Gigabit Ethernet ports with optional PoE, dual HDMI 2.0b outputs supporting 4K resolution, and intelligent vehicle power ignition control. The rugged aluminum enclosure operates across an extended temperature range from -40°C to 70°C and meets MIL-STD-810H shock and vibration standards. With E-Mark E13 certification for in-vehicle use, TPM 2.0 security, and IP65 sealing, this compact box PC delivers reliable performance in harsh environments. Available from Recab, your Nordic partner for Advantech industrial embedded computer solutions.

manufacturer

Advantech

product model

TS-207
Download datasheet
Contact an expert
CE Certified, E-Mark, FCC Class B, IEEE 802.3af, IP65 Rated, MIL-STD-810H, RoHS Compliant

Overview

The Advantech TS-207 is a military-grade fanless embedded box PC engineered for demanding transportation, outdoor, and AIoT applications requiring exceptional durability and reliable computing performance. Built around 11th Gen Intel Core U-Series processors including the Intel Core i5-1145GRE and Intel Celeron 6305E options, this rugged system delivers powerful processing capabilities with Intel Iris Xe graphics supporting hardware acceleration for various video codecs. The TS-207 features a comprehensive connectivity suite including four M12 circular Gigabit Ethernet connectors with optional IEEE 802.3af PoE support delivering up to 60W power output, making it ideal for connecting IP cameras and sensors in vehicle and outdoor installations. Dual HDMI 2.0b ports provide 4K display output at 60Hz, while two USB 3.0 ports, two M12 USB 2.0 connectors, and two RS-232/422/485 serial ports ensure versatile peripheral integration. The robust aluminum housing achieves IP65 sealing when used with optional Amphenol waterproof caps, protecting against dust and water ingress in harsh environments. Operating across an extended temperature range from -40°C to 70°C with airflow and meeting MIL-STD-810H shock and vibration standards, the TS-207 excels in mobile and outdoor deployments. Intelligent vehicle power ignition control with selectable boot-up and shutdown voltage thresholds enables seamless integration into automotive electrical systems, while E-Mark E13 certification confirms compliance with in-vehicle EMC requirements. Security features include TPM 2.0, and expansion options comprise two mini PCIe slots, one M.2 2230 E-key slot, and storage via mSATA or SATA III. Remote management through Advantech WISE-DeviceOn simplifies fleet deployment and maintenance. Available from Recab, your Nordic partner for Advantech industrial embedded computer solutions.
Expandable, Fanless, Ignition Control, In-Vehicle Ready, IP65 Rated, M12 Connector, Mounting Options, PoE Supported, Remote Management, Robust Design, Rugged Design, TPM 2.0, Wide Temperature

Key highlights

  • List Item #1
  • List Item #2
  • List Item #3

Features

  • Fanless operation across extended temperature range from minus forty to seventy degrees Celsius
  • IP65 rated enclosure with M12 connectors provides robust protection against dust and water
  • Four Gigabit Ethernet ports with optional PoE support up to sixty watts total output
  • E-Mark E13 certified with intelligent vehicle power ignition control for automotive integration
  • MIL-STD-810H compliant for shock and vibration resistance in mobile applications
  • Dual HDMI 2.0b outputs supporting 4K resolution displays at sixty hertz refresh rate

Specifications

CPU Intel i5-1145GRE (1.5/4.1 GHz) or Intel Celeron 6305E (1.8 GHz)
Memory DDR4 up to 3200MT/S, 1x SO-DIMM socket (up to 32GB)
Graphics Intel Iris Xe Graphics
Display Output 2x HDMI 2.0b with 4Kx2K support at 48-60Hz/24bpp
Ethernet 4x M12 circular connectors 10/100/1000 Mbps (optional PoE 60W)
USB 2x USB 3.0/2.0 Type-A, 2x M12 USB 2.0
Serial Ports 2x DB-9 RS-232/422/485 with auto flow control
Power Input +12/24VDC In-Vehicle with ignition control
Power Consumption Maximum 52.82W, Idle 26.1W (at 12VDC)
Operating Temperature Standard: 0-60°C, Extended: -40-70°C
Dimensions 280 x 81 x 230 mm (without wall-mounting)
Sealing Level IP65
Vibration/Shock MIL-STD-810H method 514.8, IEC 60721-3-5
TPM TPM 2.0
Certifications E-Mark (E13), CE/FCC Class B, ISO7637-2 Level 4

Applications

  • In-vehicle computing systems for fleet management and telematics
  • Outdoor AIoT edge computing in harsh environmental conditions
  • Transportation surveillance with PoE-powered IP camera integration
  • Mobile data acquisition for railway and commercial vehicle applications

Resources

Datasheet

https://recab.com/wp-content/uploads/2026/09/TS-207_DS01062620260107115629.pdf
