The Advantech AOM-5721 is a high-performance AI-on-Module powered by Qualcomm QCS6490 or QCS5430 SoC, featuring Kryo 670 CPU cores and Adreno 643 GPU for advanced AI and graphics processing. This compact SMARC 2.2 compliant module offers up to 16GB LPDDR5 memory, up to 512GB UFS storage, multiple display outputs including HDMI, DisplayPort, and eDP, along with extensive I/O including PCIe 3.0, USB 3.2, Gigabit Ethernet, MIPI-CSI camera interfaces, and CAN-FD connectivity. Supporting Yocto, Ubuntu, Windows 11 IoT, and Android operating systems, the AOM-5721 is ideal for embedded AI applications, edge computing, and industrial automation. Available from Recab, your Nordic partner for Advantech computer on module solutions.

The Advantech AOM-2721 is an OSM 1.1 Computer-on-Module powered by the Qualcomm QCS6490 or QCS5430 SoC, featuring ARM v8 Cortex processors running up to 2.7 GHz. This compact 45x45mm module integrates 8GB LPDDR5 memory, Adreno GPU 643, and comprehensive I/O including PCIe Gen3, USB 3.2, Gigabit Ethernet, MIPI-CSI camera interfaces, and multiple display outputs via MIPI-DSI, eDP, and DisplayPort. Supporting Windows 11 IoT Enterprise, Yocto, and Ubuntu operating systems, it delivers exceptional performance for embedded AI and edge computing applications within a -20 to 70°C operating range. Available from Recab, your Nordic partner for Advantech Computer-on-Module solutions.

The Advantech AOM-5521 is a state-of-the-art AI-on-Module featuring the NXP i.MX95 System-on-Chip with six Arm Cortex-A55 cores running up to 2.0 GHz, complemented by dedicated Cortex-M7 and M33 real-time processors. This SMARC 2.2 compliant module integrates 8GB LPDDR5 memory, 16GB eMMC storage, and a built-in Neural Network accelerator for edge AI applications. Connectivity includes 10 Gigabit Ethernet, dual Gigabit LAN, USB 3.2 Gen1, PCIe 3.0, CAN-FD, and comprehensive display interfaces including MIPI-DSI and dual-channel LVDS. Supporting Yocto Linux with extended temperature operation from -40 to 85°C, the AOM-5521 delivers robust performance for industrial embedded systems. Available from Recab, your Nordic partner for Advantech computer-on-module solutions.

The Advantech AOM-2521 is a compact OSM 1.2 Computer-on-Module powered by the NXP i.MX 95 SoC featuring a Cortex-A55 hex-core processor running at up to 2.0 GHz, complemented by Cortex-M7 and Cortex-M33 real-time processors. This module includes 8GB LPDDR5 memory, 16GB eMMC storage, a built-in neural network accelerator, and comprehensive I/O including 10GbE, USB 3.2, MIPI-DSI, dual LVDS, CAN-FD, and PCIe 3.0 interfaces. The ultra-compact 45 x 45mm OSM Size-L form factor supports extended temperature operation from -40 to 85°C, making it ideal for industrial automation, edge AI, and embedded vision applications. Available from Recab, your Nordic partner for Advantech computer-on-module solutions.

The Advantech SOM-6886 is a COM Express Compact Type 6 module powered by Intel Core Ultra Series 3 processors (Panther Lake-H) with up to 16 cores and 65W TDP. This high-performance computer-on-module features Intel Arc Graphics with up to 192 EU, an integrated NPU delivering 50 TOPs, and total SoC AI performance up to 180 TOPs. It supports DDR5 memory up to 128GB at 7200 MT/s or LPDDR5x up to 64GB at 9600 MT/s, offers up to 20 PCIe Gen4 lanes, USB4, USB3, and MIPI-CSI connectivity. The module operates across extended temperatures from -40°C to 85°C and is AS9100 compliant for aerospace applications. Available from Recab, your Nordic partner for Advantech computer-on-module solutions.

The Advantech SOM-M250 is a COM HPC Mini v1.2 computer-on-module powered by Intel Core Ultra 300 series processors (Panther Lake-H) with up to 16 cores and 25W TDP. This high-performance module features Intel Xe3 graphics with up to 192 execution units, integrated NPU for AI acceleration, dual-channel LPDDR5x memory up to 64GB at 9600MT/s with IBECC support, and PCIe Gen5 expansion. The module supports wide temperature operation from -40 to 85°C, dual 2.5GbE networking, USB4 connectivity, onboard NVMe SSD up to 1TB, and AS9100 compliance for aerospace applications. Available from Recab, your Nordic partner for Advantech computer-on-module solutions.

The Advantech SOM-7533/R is a COM Express Mini Type 10 computer-on-module featuring Intel Core-i, Pentium, Celeron, and Atom x7000 series processors based on Alder Lake-N and Amston Lake architectures. This compact module supports single-channel LPDDR5 memory up to 16GB with IBECC, 2.5GbE with TSN capability, and multiple I/O expansion including PCIe Gen3, USB 3.2 Gen2, and SATA 3.0. Optional onboard eMMC storage up to 64GB and TPM 2.0 enhance embedded system designs. Operating temperature ranges from standard 0 to 60°C to extended -40 to 85°C for rugged applications. Available from Recab, your Nordic partner for Advantech computer-on-module solutions.

The EMBC-CECT6 by Advantech is a COM Express Compact solution engineered for mission-critical AI applications in harsh environments. Featuring 13th Generation Intel Core i7 processor with MXM GPU support, 64GB dual-channel LPDDR5 on-board memory, and 1TB on-board NVMe storage with M.2 2242 expansion capability. This rugged computing platform operates across wide temperature ranges from -40°C to 85°C and accepts 9-15V input voltage while meeting MIL-STD-202H shock and vibration standards. The modular design enables quick CPU and GPU performance upgrades with customizable I/O board functions. Available from Recab, your Nordic partner for Advantech embedded computing solutions.

The Advantech SOM-5871 is a COM Express Basic Module Type 6 featuring AMD Ryzen Embedded V1000 series processors with Vega GPU graphics supporting quad independent 4K displays. This high-performance module offers dual channel DDR4 memory up to 32GB with ECC support, extensive I/O including PCIe x8, 6 PCIe lanes, USB 3.1, SATA III, and optional TPM 2.0 security. Operating temperature options range from standard 0 to 60°C to extended -40 to 85°C for industrial deployments. The module supports iManager and WISE-PaaS/DeviceOn for embedded management. Available from Recab, your Nordic partner for Advantech Computer On Module solutions.

The Advantech SOM-5883 is a high-performance COM Express Basic Type 6 module featuring Intel 11th Gen Core processors (Tiger Lake-H) with up to 8 cores and 16 threads. This compact module delivers exceptional computing power with Intel Iris Xe graphics supporting quad independent 4K displays, dual-channel DDR4 memory up to 128GB with ECC support, and advanced I/O including PCIe Gen4 x16, USB 3.2 Gen2, 2.5GbE Ethernet, and SATA3. The SOM-5883 includes TPM 2.0 security protection and optional onboard NVMe SSD for fast, vibration-resistant storage. Operating temperature ranges from standard 0-60°C to extended -40 to 85°C for demanding industrial applications. Available from Recab, your Nordic partner for Advantech computer-on-module solutions.
