The VadaTech VTX352 is a four-slot 6U VPX hardened chassis designed for conduction-cooled modules in rugged deployed environments. It supports VITA 66.5 for optical connectivity and VITA 67.2 for RF on its configurable backplane, with all I/O accessed via MIL-STD-38999 style connectors. Featuring dual VPX Power Entry Modules and a backplane routable to customer specifications, the VTX352 is suited to defence, electronic warfare, and radar applications requiring a compact, mission-hardened OpenVPX platform. Available from Recab, your Nordic partner for VadaTech VPX chassis solutions.

The VadaTech AMC006 is an AMC time and frequency synchronisation module providing a complete GPS, PTP IEEE 1588, IRIG, and NTP Grand Master Clock solution for MicroTCA and ATCA systems. With an onboard GPS receiver, OCXO-disciplined clock engine, three arbitrary frequency outputs, IRIG AM demodulator, Synchronous Ethernet support, and 100ns precision UTC timestamping via PCIe, it delivers exceptional timing accuracy and flexibility for mission-critical embedded computing platforms. Available from Recab, your Nordic partner for VadaTech advanced modular computing solutions.

The VadaTech XMC247 is a single-width XMC mezzanine module delivering quad 10 Gigabit Ethernet connectivity to the host via PCIe x8 Gen3, using the Intel X710-TM4 MAC/PHY. Supporting BASE-T speeds from 100BASE-TX through 10GBASE-T and flexible I/O routing options including front-panel optical, front or rear RJ-45, and 10GBASE-KR via the XMC rear connector, the XMC247 is designed for embedded networking expansion in defence, radar, and communications applications. Air-cooled and conduction-cooled variants are available per ANSI/VITA 47. Available from Recab, your Nordic partner for VadaTech XMC networking solutions.

The VadaTech VTX880 is a 2U rackmount OpenVPX chassis accommodating up to six 3U VPX payload slots with full Rear Transition Module support, compatible with 0.8-inch, 0.85-inch, and 1.0-inch pitch modules. It features a VITA 46.0-compliant star-topology backplane, redundant push/pull side-to-side cooling at 18 CFM per slot, and power supply options spanning 800W/1200W AC or 650W/1200W DC. An optional JTAG Switch Module and VITA 46.11 Chassis Manager are available for system health management. Available from Recab, your Nordic partner for VadaTech VPX chassis solutions.

The VadaTech CP212 is a 3U Compact PCI managed Layer 2/3 Ethernet switch providing 10 front-panel RJ-45 GbE ports and two optional rear P2 connector ports in a double-slot cPCI form factor. Supporting 802.1Q VLANs, IGMP v3, MLDv2, Q-in-Q QoS, link aggregation, IPv4/6 multicast, and policy-based routing with CLI and SNMP management, it is designed for embedded computing platforms in defence and industrial environments. Available from Recab, your Nordic partner for VadaTech embedded networking solutions.

The VadaTech VME217 is a 6U single-slot VME managed Layer 2 Gigabit Ethernet switch designed for embedded defence, aerospace, and industrial computing applications. It delivers 8 ports of 10/100/1000 Ethernet via RJ-45 and 4 ports via SFF transceivers on the base board, with optional expansion to 24 ports via SFP on a double-slot configuration. Supporting 4K IEEE 802.1Q VLANs, QoS, spanning tree, and up to 8K MAC addresses, the VME217 is managed via HTTP and draws power directly from the VME bus backplane. Available from Recab, your Nordic partner for VadaTech VME networking solutions.

The VadaTech VPX765 is a 3U OpenVPX processor module based on the 11th Generation Intel Core i7-1185GRE (Tiger Lake) quad-core processor, operating at 1.8 GHz base with 4.4 GHz turbo frequency. Designed for general-purpose embedded processing, it provides 32 GB DDR4 with in-band ECC, 64 GB SSD, PCIe x4 Gen4 and Gen3 to P1, an XMC expansion slot, dual GbE, and TPM-based secure boot. Configurable across air-cooled and conduction-cooled variants per ANSI/VITA 47, it suits defence, aerospace, and communications applications. Available from Recab, your Nordic partner for VadaTech VPX embedded computing solutions.
