iNA110 – DIN-Rail Fanless Cybersecurity Gateway by Axiomtek

The Axiomtek iNA110 is a fanless DIN-rail cybersecurity gateway designed specifically for ICS security and critical infrastructure protection in industrial environments. Powered by the Intel Atom x5-E3930 or x5-E3940 processor (Apollo Lake) with SoC-integrated chipset, the iNA110 is a cost-effective platform combining low power consumption with the processing capability required for network inspection and security filtering at the operational technology edge. Up to 8 GB of DDR3L-1600 SO-DIMM memory is supported alongside a 2.5-inch SATA 3.0 SSD bay and half-size mSATA slot for flexible local storage. Four GbE RJ-45 ports using Intel I210-IT controllers include one pair of LAN Bypass to maintain network continuity in the event of a system failure, a critical feature for industrial network security appliances. Wireless expansion is supported through one full-size PCIe Mini Card slot with a SIM slot for 3G or LTE connectivity, and one half-size PCIe Mini Card slot with SATA and USB signals. Additional I/O includes HDMI, two USB 3.0 ports, a console RJ-45 port, and one RS-232/422/485 COM port via terminal block. TPM 2.0 and a 255-level hardware watchdog timer are onboard for platform integrity. The wide 9 to 36 VDC power input with overvoltage, undervoltage, overcurrent, and reverse polarity protection makes the iNA110 suitable for harsh industrial power environments. With an operating temperature range of -40 to +70 degrees Celsius and IP40-rated extruded aluminium and steel construction, the iNA110 is purpose-built for substation automation, smart grid, building management, and industrial firewall deployments. Available from Recab, your Nordic partner for Axiomtek cybersecurity gateway solutions.
