TPC-200W 10.1″/15.6″ Compact Edge AI Smart Panel with Qualcomm® QCS6490 Processor

The TPC-200W from Advantech represents a new generation of compact edge AI smart panel PCs designed for demanding industrial environments. Powered by the Qualcomm QCS6490 processor with an advanced 8-core Kryo 670 CPU architecture delivering clock speeds up to 2.7 GHz, this panel PC provides exceptional computational power for real-time control, edge computing, and AI-enhanced industrial applications. The system comes equipped with 8 GB LPDDR5 onboard memory and 128 GB UFS storage, ensuring responsive performance for complex automation tasks. Display options include 10.1-inch WXGA and 15.6-inch FHD TFT LED LCD panels featuring 500 nits brightness, 178-degree viewing angles, and 50,000-hour backlight life. The 10-point projected capacitive multi-touch screen with greater than 85 percent light transmission and 7H pencil hardness ensures smooth and durable operator interaction. The rugged die-cast aluminum front bezel provides IP66-rated water and dust protection, while the fanless thermal design enables reliable operation across a wide temperature range of -10 to 50 degrees Celsius. Comprehensive connectivity includes dual Gigabit Ethernet ports, four USB 3.0 ports, RS-232/422/485 serial communication, and CAN 2.0B support. Rich wireless expansion is available through M.2 Key-B for 4G/5G modules and M.2 Key-E for WiFi and Bluetooth connectivity. Supporting multiple operating systems including Yocto Linux, Windows 11 IoT, and Android, the TPC-200W offers deployment flexibility for smart factory applications, equipment control stations, and industrial automation systems. Panel mount and VESA mount options ensure versatile installation across manufacturing environments, process control facilities, and machine automation applications. Available from Recab, your Nordic partner for Advantech panel PC solutions.
