ADAM-5080 – 4-ch Counter/Frequency Module by Advantech

The ADAM-5080 from Advantech is a versatile 4-channel counter and frequency module engineered for programmable automation controller systems requiring precise signal counting and frequency measurement capabilities. This industrial-grade module delivers reliable performance with input frequency support up to 1,000 Hz in frequency mode and 5,000 Hz in counter mode when using TTL inputs. The 32-bit counter provides a maximum count of 4,294,967,295, ensuring ample range for demanding industrial applications. The module supports both isolated and TTL level inputs, with isolation input levels accepting logic level 0 at 1 VDC maximum and logic level 1 from 3.5 to 30 VDC. For TTL inputs, the module accepts standard logic levels of 0 to 0.8 VDC for low and 2.3 to 5 VDC for high states. With 1,000 VRMS isolation voltage, the ADAM-5080 provides robust protection against electrical interference in harsh industrial environments. The programmable digital filter function, adjustable from 1 to 65,000 microseconds, effectively suppresses noise and ensures accurate signal acquisition. Counter auxiliary functions include initial preset, high-low alarm setting, alarm digital output mapping, and overflag capabilities. Operating modes encompass counter with up/down and bi-direction functionality, as well as frequency measurement. The module features a durable ABS+PC enclosure with plug-in screw terminal connectors supporting 14 to 22 AWG wiring for straightforward installation. With CE and FM certifications plus RoHS compliance, the ADAM-5080 is ideal for factory automation, process control, machine monitoring, and industrial equipment integration where accurate counting and frequency measurement are essential. Available from Recab, your Nordic partner for Advantech remote I/O solutions.
