9250 w.s Standalone Intelligent Supercapacitor-based Uninterruptible Power Backup Module

DATASHEET

• Universal standalone power backup module compatible with all box-PCs
• Supercapacitor-based, -25 to 65°C wide temperature operation
• 9250 watt-second energy capacity
• Maximum 180W output power for the connected back-end system
• Over 10 years lifespan, and 500,000 charging/ discharging cycles
• Patented CAP energy management technology*
  • Extending back-up time in the event of an unforeseen power outage
  • Monitoring energy and power consumption to extend operation time for safe system shutdown
• Versatile operating mode
  • Normal backup mode
  • Ignition control mode for standard box-PC and in-vehicle controller
• EN50155 certificate
• *R.O.C. Patent No. I598820

Introduction

PB-9250J-SA is a standalone power backup module that can protect your box-PC against power outages. Utilizing state-of-the-art supercapacitor technology, it can operate in harsh environments from -25 to 65°C, and have extremely high durability lasting over 10 years.

PB-9250J-SA is composed of eight 370F/ 3.0V supercapacitors, which offers much longer lifespan than its 2.7V counterpart, and stores 9250 watt-second energy to offer extra extended operation time to backup your system. Thanks to Neousys’ patented CAP energy management technology, It can reliably supply 180W power to the back-end system and automatically manage boot and shutdown without installing additional drivers/ software. In addition to UPS-like power backup mode, it also offers two advanced ignition control modes for in-vehicle usage. PB-9250J-SA can work with either standard box-PC or in-vehicle controller to provide stable power supply and execute user-configurable power-on/ power-off delay according to IGN signal input.

Featuring various modes, automatic shutdown control and up to 180W output power, PB-9250J-SA can work with most off-the-shelf box-PCs. And with properties such as maintenance-free energy storage and uninterruptible power supply, PB-9250J-SA can prevent the connected back-end system from data loss during power outage in harsh industrial environments!
