Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience - based best practices.
Mech-Eye 3D camera "sees" target objects, Mech-Vision "understands" depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That's where Mech-Viz comes to play - let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Executive Summary – Achieving Successful IT / OT Network Convergence
For years, office Information Technology (IT) networks and plant floor Operational Technology (OT) networks were wholly separate. On top of that, IT and OT personnel often had little to do with one another. With the advent of industrial Ethernet replacing fieldbus protocols on the plant floor, they now share a common network, creating valuable opportunities to combine resources and collaborate on goals for overall organizational success.
However, this network convergence also sets the stage for interactions – some might say showdowns – between IT and OT network personnel with very different training, experiences and cultures. The extent to which these necessary collaborations become adversarial or collaborative is dependent upon the approach taken by the organizations and individuals involved.
There is a great deal of misunderstanding about what convergence is and what it entails— for example, one group within the organization might be working toward the creation of one single, flat network while the other is attempting to segregate through technologies such as VLANs. The chances of success in this environment are low due to the steep learning curve and the opportunity for costly missteps when combining these different perspectives.
Fortunately, these challenges have become less necessary to endure. As more and more organizations converge their networks, there is a growing body of resources and best practices being published. Assistance is available through third-party consultants, manufacturer representatives and resources such as this white paper. This is a collection of experiences from Belden and partners who have helped many organizations successfully establish their own converged network. These insights can help you reduce your learning curve and benefit from a converged IT/OT network quickly and efficiently at your location.
Table of Contents for Achieving Successful IT / OT Network Convergence
⇒ Executive Summary………………………………1
⇒ What “One Network” Means…………………..2
⇒ The Benefits of a Converged Network……..2
⇒ The Value of Data…………………………………2
⇒ How to Design a Converged Network………3
⇒ Don’t Make Security an Afterthought………..3
⇒ A New Organizational Agreement…………….4
⇒ The Automation & Data Exchange (ADX) Engineer…..4
⇒ Encouraging Cooperation……………………….4
⇒ Conclusion……………………………………………4
Download white paper Send download link to:
Belden / Hirschmann IT/OT-CONVERGENCE WhitePaper
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
How do you define “flexibility and reliability”?
In Mech-Mind’s all-in-one solutions, Mech-Eye, Mech-Vision, and Mech-Viz collaborate with one another to gain greater accuracy, flexibility, and reliability in robotic operations.
Mech-Viz is an intelligent robot programming software for more reliable and efficient robotic operations. With collision detection, motion planning, and other advanced algorithms inside, Mech-Viz enables robots to tackle demanding tasks with great stability, extraordinary flexibility, and outstanding consistency.
Mech-Viz offers users a code-free programming environment and a graphical interface to solve the most challenging machine vision applications through a simple operation.
Core Advantages for code-free robot programming software for reliable robotic operations:
⇒ One-click simulation that visualizes the entire motion path of the robot.
⇒ Powerful AI algorithms, including motion planning, collision detection, optimal grasping planning, mixed palletizing algorithms, etc., to enable smooth and reliable robotic operations and solve complex robot applications.
⇒ A code-free graphical user interface allows users to deploy applications without writing a line of code.
⇒ Support for almost all major-brand robots.
⇒ Multiple language packs for one-button switching of software languages.
Applications for code-free robot programming software for reliable robotic operations:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Industrial 3D camera and software for intelligent robotics.
Mech-Mind is an industry-leading company focusing on industrial 3D camera and software suite for intelligent robotics. Leveraging 3D vision and AI technologies, products who enable industrial robots to tackle challenging automation tasks. Typical applications include bin picking, depalletizing & palletizing, pick & place, and more. The full-stack product portfolio includes patented industrial 3D camera Mech-Eye, machine vision software Mech-Vision, deep learning software Mech-DLK, and robot programming software Mech-Viz.
System integrators can we deliver demanding robotic systems
Recab will be committed to helping global system integrators to be ahead of the market. We empower them by providing easy-to-use solutions at a competitive price. With the mature AI+3D solutions, system integrators can we deliver demanding robotic systems with ease for their customers. We can also offer comprehensive support for training, marketing, and project collaboration.
About Mech-Mind:
Founded in 2016, Mech-Mind has deployed 3000+ solutions in 50+ countries and regions. They partner with customers from various fields, including automotive, logistics, home appliances, food, and beverage, etc. such as:
Popular FAQs for Mech-Eye Industrial 3D Camera:
Q1: What is an industrial 3D camera?
An industrial 3D camera is a camera used in industrial applications which can capture objects and reconstruct them from a three-dimensional image. It’s been increasingly used in diverse industries, especially in manufacturing and logistics.
Q2: How does the industrial 3D camera work?
Usually, industrial 3D cameras work with robots to complete various industrial tasks like bin picking, machine tending, assembly, inspection, measurement, etc. Industrial 3D cameras can be mounted on the arm robots to capture and collect 3D data of the target objects, which is fundamental for robots to execute further steps like picking & placing, loading & unloading, etc.
Q3: What are the main features of Mech-Eye industrial 3D cameras?
Mech-Eye industrial 3D cameras feature high accuracy, fast processing speed, and high-cost performance. Mech-Eye industrial 3D cameras have full model options, which cover a wide range of industrial applications with diverse requirements on working distance, accuracy, ambient light resistance, etc.
Q4: What are the most used applications of Mech-Eye Industrial 3D Cameras?
Mech-Eye industrial 3D cameras can be used in almost all common robot applications, including bin picking, machine tending, palletizing & depalletizing, automated piece picking, assembly, etc.
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
NVIDIA Industrial computer – ideal for solutions in harsh environments
Axiomtek’s AIE100A-ONX, an ultra-compact edge AI system, is powered by the NVIDIA Jetson Orin NX module that features a powerful 8-core/6-core ARM® Cortex® A78AE processor delivering up to 100 TOPS of AI performance and integrates an advanced 1,024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores. Equipped with a 15W GbE PoE port, the AIE100A-ONX offers a ready-to-deploy IP camera with both power and video transmission. An optional waterproof IP42-rated cover kit is also designed for strengthening the protection of semi-outdoor environments. This AI-powered edge system provides an ideal solution for smart city, next-gen robotics, and autonomous machines.
Artificial Intelligence of Things (AIoT) into reality.
Annie Fu, a product manager of the AIoT Division: “Axiomtek has been in close collaboration with NVIDIA in driving AI innovation at the edge. Axiomtek’s AIE100A-ONX is specifically built around the NVIDIA Jetson Orin NX system-on-module. It is integrated with the latest NVIDIA Ampere architecture GPU and NVIDIA Deep Learning Accelerators, which deliver up to 5x the performance compared to the previous generation,” Annie Fu continue with: “With NVIDIA’s AI and accelerated computing technologies, Axiomtek continues to deliver advanced hardware platforms and data communication solutions for deploying AI to the edge, helping customers speed up the implementation of deep learning capabilities into their IoT devices and turn Artificial Intelligence of Things (AIoT) into reality.
Feature:
⇒ NVIDIA® Jetson Orin™ NX with 1,024-core NVIDIA Ampere GPU
⇒ High AI computing performance for GPU-accelerated processing
⇒ Ideal for edge AI smart city applications
⇒ Supports one 15W GbE PoE for camera
⇒ Wide operating temperature from -30°C to +50°C
⇒ JetPack supported
⇒ Supports 24/7 secure remote monitoring, control, and OTA deployment empowered by Allxon
Development for AI computing and deep learning applications
Axiomtek’s AIE100A-ONX supports rich I/O interfaces, including one USB 3.2 Gen2 port, one USB 2.0 port, one Micro USB port, one GbE LAN, one GbE PoE and one HDMI 2.0 with 4K2K. It will also offer support for NVIDIA JetPack™ 5.1 for ease of development for AI computing and deep learning applications such as autonomous machines, robotics, computer vision and more. For stable operation in mission-critical environments, the AIE100A-ONX has a wide operating temperature range of -30°C to +50°C and anti-vibration of up to 3 Grms. Additionally, AIE100A-ONX supports Telit’s LE910C4 series 4G LTE modules for faster data transition and more advanced IoT connectivity.
Download datasheet
Send download link to:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
A new 3U VPX conduction-cooled plug in card based on the Intel® Xeon® W-11000E Series processor (formerly known as Tiger Lake-H). TheTR L9x/6sd-RCx has been designed in alignment with the SOSA™ Technical Standard for I/O intensive processor boards by Concurrent Technologies. There are two processor options: an 8-core solution fitted with the Intel® Xeon®
Feature:
⇒ Up to 8-core processor for high performance
⇒ Up to 100G Ethernet Data plane
⇒ PCI Express Expansion plane for high speed communication with adjacent board(s)
⇒ XMC site for additional I/O resources
⇒ Optional M.2 module for storage with Write/Protect and Opal 2.0 compliance
Rugged 3U VPX Card with SOSA™ Technical Standard
TR L9x/6sd-RCx has been designed in alignment with the SOSA™ Technical Standard for I/O intensive processor boards. There are two processor options: an 8-core solution fitted with the Intel® Xeon® W-11865MRE processor; a 4-core solution fitted with an Intel® Xeon® W-11155MRE processor. Both of these processors come with an integral GPGPU engine with 32 Execution Units which can be used for display or acceleration purposes using OpenCL™, OneAPI or OpenVINO™ for image processing or Artificial Intelligence. TR L9x/6sd-RCx is the first processor board from Concurrent Technologies to support up to 100GBASE-KR4 Ethernet capability which makes it suitable for many future applications needing high throughput communications. TR L9x/6sd-RCx supports a range of standard security capabilities including Boot Guard, Total Memory Encryption and is fitted with a Trusted Platform Module for key storage. In addition, Concurrent Technologies offers an additional Guardian Package for enhanced security.
Link to Recab’s range of Concurrent solutions.
Link to Concurrent https://www.gocct.com/
Download datasheet for Rugged 3U VPX Card
Send download link to:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Nuvo-9000 Series – Intel® 12th-Gen Core™ Fanless Industrial PC with 6x GbE, USB 3.2 Type-C, Patented Cassette & MezIO™ Interface
Nuvo-9000 series is Neousys’ Combining the increase of DDR5 memory bandwidth and PCIe Gen4 NVMe high-speed disk read/write, users can expect an overall system performance improvement of up to 1.8x when compared to previous 10th or 11th-Gen platforms.
Feature:
⇒ Supports Intel® 12th-Gen Alder Lake Core™ 16C/ 24T 35W/ 65W CPU
⇒ Patented Cassette for PCI/PCIe add-on card accommodation
⇒ Rugged, -25°C to 70°C fanless operation
⇒ Up to 5x 2.5GbE and 1x GigE ports with optional PoE+, supporting 9.5 KB jumbo frame
⇒ 1x USB 3.2 Gen2x2 type-C and 6x USB 3.2 Gen2x1 type-A ports
⇒ Supports M.2 Gen4x4 NVMe and 2x SATA ports
⇒ MezIO™ interface for easy function expansion
⇒ VGA/ DVI/ DP triple independent display, supporting 4K2K resolution
Great versatility by allowing additional installation of PCIe or PCI add-on cards.
Nuvo-9000 series inherits Neousys’ patented expansion Cassette design to provide great versatility by allowing additional installation of PCIe or PCI add-on cards. There are three expansion Cassette options available for Nuvo-9000 series, the Nuvo-9000E features a single x16 Gen3 PCIe slot; Nuvo-9000DE has dual x16 PCIe slots, and Nuvo-9000P has a single PCI slot. For users who need more flexible storage, Nuvo-9000LP has a 2.5″ HDD tray instead of an expansion Cassette to support a hot[1]swappable 2.5″ HDD/SSD.
An upgraded M.2 Gen4x4 slot to support the latest NVMe SSD
I/O functions are also comprehensively enhanced. In addition to six gigabit Ethernet ports with PoE+ PSE option, Nuvo-9000 series features a USB 3.2 Gen2x2 type-C port offering 20 Gbps bandwidth for data exchange with external devices, plus another six USB 3.2 Gen2x1 type-A ports for USB3 camera connectivity. It also has an upgraded M.2 Gen4x4 slot to support the latest NVMe SSD to boost disk read/write speed up to 7000 MB/s. For unfulfilled I/O requirements, users can utilize the expansion Cassette to add on function-specific PCIe/ PCI card, the proprietary MezIO interface, and internal mini-PCIe/M.2 interfaces.
With its field-proven thermal design, significant CPU and I/O upgrades, and multiple expansion methods, the Neousys Nuvo-9000 series fits your need for ruggedness, performance, and versatility for a variety of applications.
Link to Recab’s range/articles of Rugged embedded computer
Link to Neousys
Download datasheet here
Free download
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Broad UV sensitivity
The GO-8105M-5GE-UV offers excellent sensitivity for applications across the UV spectrum. QE at 200 nm is around 25% meaning that even advanced applications requiring imaging well into the UVC spectrum are fully supported. The combination of high resolution and high sensitivity creates a wide range of possibilities for vision system developers.
Glass or glassless configurations
The GO-8105M-5GE-UV comes standard with a double-AR-coated, quartz glass cover over the sensor to protect the sensor from dirt and damage while maximizing light transmission. A glassless version (GO-8105M-5GE-UV-GL) has a protective glass cover on the sensor that can be removed by the user for applications where cover glass interference is problematic.
Small and reliable
The GOX-8105M-5GE-UV provides robust capability in a small form factor. The camera weighs less than 100 grams but carries shock and vibration ratings of 80G and 10G, respectively, to ensure that it can perform reliably in both industrial and scientific applications.
Feature for the UV area scan camera GO-8105M-5GE-UV:
⇒ 8.1-megapixel monochrome camera with 2.74-micron pixels and 2/3” optical format.
⇒ Backside-illuminated Sony Pregius S IMX487-AAMJ image sensor with enhanced UV sensitivity to 200 nm and below.
⇒ High performance GigE Vision 2.0 interface can automatically negotiate between 5GBASE-T, 2.5GBASE-T, and 1000BASE-T speeds as needed.
⇒ Can be powered over the interface (PoE) or from an external power supply via 6-pin Hirose connector.
⇒ Small and lightweight form factor (less than 100 grams).
⇒ Mounting holes with 21 mm or 20 mm spacing to fit most existing installations with no re-tooling required.
⇒ Industrial grade performance with ratings of 80G shock, 10G vibration, plus excellent thermal dissipation.
⇒ Available with quartz glass covering sensor or with user-removable protective glass for glassless applications.
⇒ Includes “Xscale” function supporting virtual, sub-pixel rescaling of output for greater binning flexibility or when matching the resolution and FOV of cameras in existing systems.
Applications where Go Series UV-sensitive cameras are especially suitable:
Electronics and corona inspection: Solar panels and other types of electronics may need UV imaging to look for signs og current leakage or other defects. UV cameras are also used to inspect power lines and transformers where non-visible “coronas” can indicate electrical problems.
Medical/Dermatology: UV lighting and imaging can detect damaged skin and subsurface issues at early stage before they become serious.
Semiconductors: UV cameras let inspections systems utilize extremely short light wavelengths so the smallest defects or surfaces can be imaged and analyzed
Pharmaceuticals:
Visions system for track and track and trace, pill sorting, inspecting vials and ampoules, and many other applications, often need to be able to “see” invisible product codes, lo numbers or other markings.
Security printing inspection: Bank notes, passports, lottery tickets, and other similar items may use special security markings only visible in the UV spectrum
Download datasheet Send download link to:
Jai: Go Series 8.1 MP UV area scan camera
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Shortage of electrical components is a significant problem for many companies
As the industry keeps struggling with component shortages on just about every level, the shortage of electrical components is a significant problem for many companies.
In particular, we see a trend in the field of FPGAs, where the major vendor’s last-generation FPGAs are now typically difficult or even impossible to purchase. Lead-times for new orders may be 12 months or more and prices at distributors have risen to up to 100 times the normal prices in some cases.
This has led to a trend of saving lead-time and sometimes money by replacing these hard-to-find FPGAs with newer FPGAs from other vendors who can deliver the parts on time and at a lower price. But this requires a usually non-trivial effort to migrate the FPGA design to the new target and in most cases also a new hardware spin to accommodate the new FPGA footprint.
Synective Labs offers a unique expertise within the FPGA.
As a leading expert in FPGA-systems, Synective Labs, a Recab company, have unique expertise and experience working with just about every tool chain and FPGA vendor in the industry. This includes partnerships with AMD/Xilinx, Intel/Altera and Achronix as well as experience working with Lattice, MicroSemi and Efinix.
We can therefore quickly recommend a suitable replacement FPGA for any given design and help the customer find the fastest way to migrate to the new part.
We also offer our services performing the design migration, taking the old and new target FPGA’s unique features into account for an optimal solution. Finally, we can also help updating schematics to assure proper operation in terms of power, booting, clocking, reset and I/Os etc. as well as performing initial bring-up of the updated hardware in the lab.
Challenge for the Synective Labs team
In a recent project, one of our customers had the need to replace a 45nm hard-to-buy FPGA in a 7-year-old design. As the customer’s hardware had gone through some rather extensive qualification process, it would have been very time-consuming to re-design the PCB and re-qualify the hardware. Instead, Synective Labs helped the customer replace the older FPGA with a new FPGA mounted on an interposer-card which acted as an adapter between the new and the old FPGA footprint. This means the customer got a drop-in replacement component without having to re-design any other hardware or do any re-qualification which saved time and money.
Synective Lab’s experts were able to migrate the vendor-specific elements such as memory blocks, PLLs, clock networks, I/O-buffers and boot-structure to the new FPGA’s counterparts and re-target the design. The Interposer assembly was then used as a drop-in replacement for the old FPGA in the existing product without any changes to the main PCB or the firmware.
Benefits for the customer
The benefits of this approach to the customer were in summary:
⇒ Manageable lead times of FPGA component
⇒ Reduced price for purchasing the FPGAs
⇒ No need for re-qualification of product
⇒ No need for any major firmware or software update
⇒ Better power and thermal management due to newer FPGA technology
Download the solution in a PDF
Send download link to:
Synective Labs – FPGA Drop in Replacement
About Synective Labs – The FPGA Experts
Synective Labs is specializing in FPGA technology and FPGA based solutions with focus on high performance systems. Our offerings range from development of complete systems to assisting in our customers’ development process, helping them to design better products. We operate in a wide range of technology fields like Automotive, Telecommunication and Image Processing where we have long experience and specific domain knowledge. www.synectivelabs.se
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Immediate product delivery for your project
We supply PanelPC’s, BoxPC’s, COMe Modules, Embedded Motherboards, 19” Industrial Server’s, including custom specific variants.
At Recab we have continuous dialog with our manufacturing partners, we can offer a short delivery time for yor projects, we also have the option to customize the products to suit you – see a selection from our partners who can deliver at short notice:
⇒ Neousys
⇒ Sintrones
⇒ Axiomtek
⇒ Aplex
⇒ JAI
⇒ Hirschmann
⇒ Keyence
⇒ Aaeon
⇒ Supermicro
⇒ Innodisk
Let us present a selection of products with short delivery time:
About Neousys Technology
Established in 2010, Neousys Technology designs and manufactures industrial grade rugged embedded computers and systems with core expertise ranging from embedded computing to data acquisition and processing.
Ideal solutions for automation, machine vision, transportation, GPU computing, surveillance and video analytics.
Besides the products Nouvo-8111, Nouvo-7000LP series & the SEMIL-1700GC Series, can we offer a range of solutions your projects.
About Sintrones
SINTRONES is a world-renowned and ISO 9001 & IRIS ISO/TS 22163 certified company of in-vehicle computing system products. They are dedicated to provide our customers with high quality system products that meet international traffic standards certification, including EN50121, EN50155, E-Mark, IEC60945, IACS E10, DNV and MIL-810.
Besides the products VBOX-361-IP65, ABOX5210G6-M12X and the SBOX2601 can we offer a range of solutions for your projects.
About Axiomtek
Axiomtek comprehensive product lines include embedded board, system on module, single board computer, embedded system, industrial barebone, network appliance, touch panel computer, human machine interface, medical PC, industrial network, and digital signage.
Their creative concept of integrated services for embedded computing assures trusted delivery and valuable system integration from board-level design-in to system-level design for vertical markets in automation, transportation, gaming, power utility, POS, kiosk, retail, network security, medical, digital signage, green power and much more.
Besides the products CAPA500, MANO560, MANO0315, IMB530 & the SHB150R, can we offer a range of solutions for your projects.
About Aplex
Aplex’s main products include HMI Controllers, Industrial Panel PC, Engine Box PC, Industrial Display Monitors, etc.
They apply to equipment automation, factory management, monitoring systems, and even automation in daily life. They cover logistic management systems, intelligent transportation management systems, building automation and monitoring systems, kiosk systems, etc.From common factory production to commercial automation, transportation, medicine, and so on, Aplex can provide related hardware platforms and complete service and solutions to meet customers’ needs in different industries and applications.
Beside the products ARCHMI-815AP/R(H), FABS-817P/R(H), ViTAM-919AR/P/G(H), ARCDIS-121APRG(H) & the AVS-520, can we offer a range of solutions for your projects.
About JAI & the Go-X series
Go-X Series from JAI. Compact, affordable industrial cameras designed to power the next generation of machine vision systems. Get low field failure rates, a six-year warranty, unrivalled shock and vibration standards and market-leading dust protection.
JAI provides innovative digital CMOS camera technology for applications in industrial machine vision, medical imaging and outdoor imaging applications, as well as complete camera subsystems for traffic imaging/vehicle recognition in Intelligent Traffic Systems (ITS). Besides the GO-X Series can we offer a range of solutions for your projects.
About SUPERMICRO
SUPERMICRO are committed to delivering first to market innovation for Enterprise, Cloud, AI, and 5G Telco/Edge IT Infrastructure. They are transforming into a Total IT Solutions provider with environmentally-friendly and energy-saving server, AI, storage, IoT, and switch systems, software, and services while delivering advanced high-volume motherboard, power, and chassis products.
Besides the products IoT Super Server SYS-110PFDWTR, IoT SuperServer SYS-220HE-FTNR & the IoT SuperServer SYS-E302-12D4C, can we offer a range of solutions for your projects.
About AAEON
Committed to innovative engineering, AAEON produces integrated Industry 4.0 solutions, cutting-edge AI hardware, and IoT solution platforms that seamlessly consolidate virtual and physical networks. They also develop hardware and intelligent automated services for premier OEM/ODMs and system integrators worldwide. There reliable, high-quality computing platforms include industrial motherboards and systems, industrial displays, rugged tablets, PC/104, PICMG and COM modules, embedded SBCs, embedded controllers, network appliances and related accessories.
Besides the products BOXER-8221AI, BOXER-8230AI, BOXER-8251AI, ICS-6270 & the MIX-EHLD1, can we offer a range of solutions for your projects.
About Innodisk
Innodisk is a service-driven provider of industrial embedded flash and DRAM storage products and technologies, with a focus on the enterprise, industrial, and aerospace industries.
They pioneered Pin 7 VCC technology in the SATA interface, an Innodisk breakthrough that eliminates the need for power cables. This, in turn, enabled us to develop the SATADOM® form factor, a revolutionary interface-powered memory solution that has been certified by Intel and widely adopted by industrial and embedded system makers across the globe.
Besides the SSD, M2SSD & the DRAM Memory Models we have a can offer a rang of solutions.
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
A modular industrial patch panel – connect up to 6 modules
The new MIPP™ is a termination panel for cables that need to be connected to active equipment such as switches. Thanks to the modular design, MIPP™ can be linked to create a large single patch panel, to which, for the first time ever, both fiber and copper cables can be connected.
Available in a choice of modules suitable for both fiber and copper cables, up to 6 modules can be connected to create a single panel that can accommodate both types of cable at the same time for maximum system flexibility. Using patch cords to connect to active equipment, cables can be terminated outside the cabinet in an organized and structured manner to ensure the highest level of reliability.
Applications
The MIPP™ is ideal for use in a wide range of industrial applications requiring maximum
system reliability and flexibility. The industrial design makes it highly suited for use in
⇒ Machine Building
⇒ Transportation
⇒ Alternative Power Generation
⇒ Power Transmission & Distribution
⇒ Oil & Gas markets
⇒ More general use in enterprise, buildings and other applications.
Benefits
The MIPP™ is designed for industrial use, where its functionality and reliability can
make a significant contribution to the uptime and availability of the system. Thanks to its
modular design, installation is quick and easy, saving time and significantly reducing initial set-up costs, whilst at the same time contributing to greater reliability and easier and more efficient system management, requiring less maintenance.
The MIPP™ has a lightweight aluminium structure which increases its overall versatility.
It can easily be mounted on a DIN Rail, or it can even be attached at the sides of the cabinets simply using a wall mount plate. Thanks to its small housing, high port density and modularity, cabinet space is kept to a minimum.
Link to Recab’s range of Hirschmann
Link to Hirschmann
Download datasheet
Send download link to:
Hirschmann – MIPP a modular industrial patch panel
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Unmanaged Industrial Media converter in an IP30 aluminum case
IMC-563P is a 10/100/1000 PoE+ port and an FX/GbE SFP port industrial mini converter from fiber to PoE+ for long-distance PD connectivity to the network center using fiber. Compatible with third-party devices, the multi-rate SFP port is compatible with different SFP modules and sends data to the Surveillance Cameras, Wireless Access Points, and other devices.
The media converter uses LED signals for users to monitor the link connectivity. This device fits in the palm of a person’s hand and can be installed on DIN rail or in a bullet camera with the help of an adapter. The media converter uses two power input methods, a terminal block and in DC power input, for versatile installation that suits the place where the device is stored.
This media converter is built with industrial grade components and enclosed in an IP30 aluminum case with high thermal conductivity, which protects the device from tools and hazards. Designed to withstand vibration, shock, free fall, interference, and temperatures ranging from -40℃~75℃ (-40°F~167°F), it suits extreme industrial applications. To ensure reliability the redundant power supply and alarm relay contact on the terminal block ensures non-stop operations and issues alerts if power fails.
Feature:
⇒ Compact size- The converter’s compact size is suitable to place it in the outdoor IP camera enclosure. Some space limitation areas are more suitable to install this device.
⇒ Easy plug and play operation – Media converter is an easy-to-setup and ready-to-use solution for PoE application system. The media converter automatically detects and configures the best mode of operation over a link. This eliminates the need for user setup or configuration procedure and simplifies installation, once installed these media converters operate automatically.
⇒ Multi-rate SFP slot – Equipped with one multi-rate 100/1000Mbps SFP slot, the media converter offers fiber advantages of secure data transmissions over long distances to missioncritical networks. It provides maximum bandwidth flexibility and extended connectivity for workgroups that are ready to expand and migrate from existing fast Ethernet network to gigabit network
Note: The Fiber and Copper port speed must be same for media converter to function.
Link to Recab’s range of Network Communications
Link to Volktek
Download datasheet
Send download link to:
Volktek – IMC-563P – Unmanaged Industrial Media converter
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
MILSTD-1553 & ARINC – high performance avionics systems
From inception in 2007, Alta Data Technologies (Alta) has grown to be a leading supplier of MILSTD- 1553 and ARINC connectivity products. With over 60,000 items shipped, Alta has proven to be one the Aerospace industry’s key technology drivers, and their wide-array of interface cards and real-time appliances has aids other companies to offer smaller, higher performance avionics systems at dramatically lower costs
An example of new high performance avionics systems are product offerings from Systems Integration Plus (SIP) of Scottsdale, Arizona. Formed in 1988 as a full-service systems integrator specializing in configuring COTS computer equipment. SIP’s expertise quickly broadened to include, and later showcase, installation and configuration of popular RTOS operating systems. By the mid-1990’s SIP added software engineering capability to develop device drivers, firmware, middleware, applications, and graphical user interfaces.
Today, SIP is a leader in COTS electronic packaging and software design bolstering its roots in system integration. Recent major system wins have included Alta’s interface cards, which helped expand SIP’s market reach, and win some large avionics projects. Gunnar Buzzard, CEO of SIP, comments:
– “We bring multiple technologies, vendors and innovative design practices as a system solution for the customer base. This includes modified COTS, or changing that last 10 percent of a COTS design, to meet specific customer needs while maintaining a strong hold on the support, logistical and long-term cost savings of a COTS based solution.“
Designs to minimize cost
“For many applications in the defense market, 1553 and ARINC interfaces are required. In 2018 we launched our HAWKEYE and GREYHOUND rugged computers with Alta as our databus solutions partner. Together we identified and planned products based on Small Form Factor (SFF) designs to minimize cost with the most technically advanced solutions. This type of technical and marketing partnership is a key factor in our success. We’re excited about Alta’s new MEZ-E1553 Ethernet mezzanine micro-card that will allow us to offer quick design turns for 1553 systems based on the latest Intel i7-i9 and Atom processors. Their new MACsec Ethernet products will, once again, be industry leading interfaces.”
Jake Haddock, CTO of Alta states:
– “Our products target the COTS or modified COTS integrator to provide the most flexible avionics network options to their end-use customer. When we first saw SIP’s strategy, we recognized the potential synergies between our companies. Our Mini PCI Express, XMC and PMC boards, along with our real-time Ethernet converters, compliments SIPs’ modified COTS strategy. Their designs enable the customer to buy a lower cost, lab-grade system for prototype or development, and then directly migrate to a fully MIL qualified rugged, deployed system with little to no changes. All with quick delivery in weeks—not months. This is a significant technical, cost and time risk reduction for programs.”
At look at recent systems shipped by SIP include a rugged support computer forthe C-17, and an even smaller, avionics mission computer for the AC-130 Gunship, MC-130 and F-16 platforms. For the C-17system, SIP used their Hawkeye (pictured) system with Intel i7 processor, two Alta XMC MIL-STD-1553 and ARINC interface cards, and other COTS serial mini PCI Express modules to produce a system that was smaller, much more powerful, and about 30% less cost. The customer began development with the lab grade system, and then seamlessly moved to the full MIL rugged systems. For the C-130 and F-16 projects, SIP has shipped their full MIL grade Greyhound (about half size of the Hawkeye), mini system with Alta mini PCI Express 1553 cards, which are about half the size of a match book. SIP has already shipped 100s of these systems, with significant orders to follow.
SIP systems can be tailored with:
⇒ Various multi-core processors
⇒ Multiple Ethernet 1G and 10G ports (copper or fibre)
⇒ Extended temperature solid state memory
⇒ RS-232/422/485 and USB ports
⇒ Digital discretes, 3G-SDI
⇒ Video
⇒ Removable storage
⇒ UPS battery
⇒ Custom I/O from DB to 38999s connectors, etc.
More new products with in the MILSTD-1553 & ARINC – MEZ-E1553 mezzanine card
Another new Alta product provides even more flexible avionics design solutions. The MEZ-E1553 mezzanine card has multiple 1553 channels (and soon Enhanced Bit Rate 1553 – EBR) with an Ethernet backplane on a mini PCI Express size card. There are several advantages for a customer to select an Ethernet connection over a PCI Express or USB. First, is the portability of development applications to almost any operating system (OS), or further OS revisions. As almost every OS has Ethernet “socket” drivers built-in, where PCI Express and USB devices require custom device drivers that can go obsolete, or not be portable between OSes.
Next generation of 1553-Ethernet product
The second advantage is the ease of designing an Ethernet connection with almost any FPGA or processor design kit. These technologies almost always include reference designs and direct Ethernet support. Alta offers a MEZ-E1553 reference card with Ethernet, USB power, and design schematics that can connect to any computer system for software development and hardware verification.
The portability and simplicity of Alta’s 1553 and Ethernet protocol engines,
along with their modular, abstracted software development kit (or API) allows the customer to use their same application code across all of Alta’s product line— often without any code changes. This includes applications developed on PCI or PCI Express cards that can run directly on their Ethernet ENET, NLINE and MEZ-E1553 products, often without recompiling (actually run the same, raw executable between all products).
Alta’s next generation of 1553-Ethernet products will incorporate IEEE-802.11ae standards for secure, highly reliable, deterministic latency links. Alta plans to release various ENET and NLINE (1553 and ARINC electronics built directly in rugged cable assemblies) products with MACsec technology to address the obvious needs to provide a cyber secure connection between the computers an ENET end-point device. MACsec provides an encrypted link between end-point devices and switches, making physical intrusions virtually impossible. The first ENET products with MACsec will release towards Q3 2022.
Products shipping with 2-3 weeks & 5-year limited warranty
Alta products includes an industry leading 5-year limited warranty, and software updates are provided at no-cost for life. Products typically ship within 2-3 weeks, even during the recent supply chain turmoil when many vendors had to push shipments out weeks or months.
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Feature ARM-based industrial IoT and automation gateway:
⇒ Industrial grade ARM-based system with pre-installed Debian
⇒ Microsoft Azure and AWS IoT Greengrass
⇒ Field-ready isolated DI/O and serial ports
⇒ 8 to 25V wide-range DC input
⇒ -25°C to 70°C wide temperature operation
Download datasheet
Send download link to:
Neousys – IGT-20 ARM based Industrial IoT and Automation Gateway
IGT-20 Series – automation gateway
The IGT-20 is based on AM3352 from Texas Instrument’s Sitara AM335x family and will be shipped as a ready system pre-installed with Debian. The industrial nature of IGT-20 means it is in compliance with common industrial certifications such as CE/FCC, shock and vibration. Another distinction IGT-20 has over SoM is that it accepts a wider range of power inputs ranging from 8 to 25 VDC (SoM usually accepts 5 VDC).
Four built-in isolated digital output channels
IGT-20 Series IoT Gateway has I/Os that are applicable to a range of industrial grade sensors. It features one USB2.0, one 10/100M LAN, two configurable COM ports (RS-232/422/485) and an optional CAN bus port. In addition to the ports mentioned, there are 4 built-in isolated digital input channels that accept discrete signals from various sensors or buttons/ switches. There are also four built-in isolated digital output channels to control actuators and indicators.
Users can take advantage of six programmable status LED indicators
Communication wise, IGT-20 has a mini PCIe slot and a USIM holder allowing it to transmit acquired data and system status via 3G, 4G or WiFi (mini PCIe WiFi module). There is an opening on top of IGT-20 for users to mount the SMA connector of the wireless module. In terms of storage, IGT-20 has dual microSDHC slots, one internal and one external. This design allows users to separate system/ user data and can expedite in OS deployment for mass production. As a gateway, users can take advantage of six programmable status LED indicators and two control buttons to operate IGT-20 without using a keyboard/ mouse.
Download datasheet
Send download link to:
Neousys – IGT-20 ARM based Industrial IoT and Automation Gateway
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Gigabit Ethernet Switches the BXS – faster data transfer
High data rates enable fast data transfer for a wide range of applications, including passenger information systems, advertising opportunities, IP cameras and more
Easy to install and maintain with a compact design, cabinet-less mounting and Powerover Ethernet (PoE+) port options that eliminate the need for separate cabling to
power end devices
Withstands harsh conditions of transportation and rail markets, including high temperatures, high vibration and electrostatic discharge.
Key Features for Gigabit Ethernet Switches
⇒ 60 W PoE power supply and optional PoE+ enables terminal equipment to be powered without additional cables
⇒ Vibration-proof M12 connectors for uninterrupted communication
⇒ EMC and fire prevention compliant
⇒ Real-time TSN Ethernet support for precise data transmission
⇒ Advanced security features, including wire-speed access control lists (ACL) and automatic denial-of-service (DoS) prevention
⇒ Extended temperature range of -40°C to +70°C
⇒ Compact, IP40 metal enclosure
⇒ Built-in Layer 2 protocols and wholistic diagnostics
⇒ Supports HiOS software
Your Benefits
The Hirschmann Gigabit BXS switches were uniquely designed for transportation markets. Not only can the switches withstand the high vibration and wide temperature ranges found in road and rail applications, but they meet all electromagnetic compatibility (EMC) and fire prevention requirements for rail vehicles.
With PoE and optional PoE+ port capabilities, users save costs by eliminating the need for separate cabling to power end devices, such as IP cameras. Additionally, TSN technology on all ports enables precise data transmission and guarantees bandwidth for dedicated network services.
Applications
Hirschmann’s Gigabit BXS switches are an ideal solution for industrial engineers and train builders looking for:
⇒ Fast data transfer for a wide range of infotainment applications, including passenger information systems, advertising opportunities and wireless internet access, to enhance the passenger experience.
⇒ Simple, cost-effective connectivity to terminal equipment for IP cameras, VoIP telephones and WLAN access points, via PoE.
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Photoelectric sensors for anyone who wants a signal when a product is in place
Solution with the photoelectric sensors PZ-G series from Keyence will save you time and secure your production line. The photocell is suitable for anyone who wants a signal when a product is in place, for example in industries such as:
⇒ Food & beverage
⇒ Medicine & health
⇒ Military
⇒ Automotive
Alignment indicator takes the guesswork out of long distance sensors setup
Has your receiver been knocked out ofalignment? How can you tell?
Thrubeam PZ-G models feature a bright red LED indicator that alerts you the instant proper alignment has been obtained. This simple yet crucial feature allows you to troubleshoot setup and run-time issues quickly, before they can escalate into major problems.
Laser Marked tags eliminate possible contamination
All information (model#, serial#, etc.) is laser marked directly onto the sensor
housing. There are no labels, inks or paints to peel or chip off into your products.
One-Touch mounting brackets cut installation time
Our unique one-touch brackets can save you and your customers considerable time
during installation or replacement.
⇒ PZ-G- Series is available in Sweden and Norway
Link to Recab’s range of Keyence solutions
Link to Keyence
Read our guide about sensors
Send download link to:
What is a sensor – Guide
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Functions for Even Greater Usability
Quantitatively confirm printing quality. Prevent causes of reading errors before they occur:
⇒ Matching level function – Check the reading margin using numerical values
Rather than confirming whether reading was possible or not, a code’s quality can be checked using a scale of 1 to 100. To prevent reading errors from occurring, the marking quality degradation is analysed and utilised for predictive maintenance such as feedback on the marking process.
⇒ Code verification function (indication values)
Verification according to standard-specified print quality criteria
The SR-2000 Series offers a code verification function for tasks with growing importance including ensuring reading stability in later processes and offering support for print quality control requests from suppliers.
Complying with the new ISO/IEC 15416 standard, this function verifies both 2D codes and barcodes for a wide range of code verification support. This function can also be used for both “offline” and “inline” production.
Supported standards:
♦ ISO/IEC 15416
♦ ISO/IEC 15415
♦ ISO/IEC TR 29158 (AIM-DPM-1-2006)
♦ ISO/IEC 16022
♦ SAE AS9132
♦ SEMI T10-0701
⇒ Lighting attachment – One-touch mounting with no need for a power supply
The SR-2000 Series is available with a newly developed external lighting attachment that does not require a power supply while allowing codes to be illuminated from a variety of directions. This attachmentis effective for code verification functions or reading direct part markings, such as markings on targets with a mirror finished surface. Using this attachment greatly improves cost savings compared with general external lighting.
Functions that facilitate reading and data processing for greater on-site usability
⇒ Always-on function – Reading with minimal movement through overhead placement. With conventional models, work occurred in three steps: Take the product in one hand. Take the handheld code reader in the other. Scan the code. Thanks to the SR-2000 Series’ “Always-On” function, reading is done just by taking the product in hand, and users will not even notice the light from the reader itself.
⇒ Advanced multi head function – Reading of an even larger field of view or of multiple surfaces. The SR-2000 Series not only offers an ultra-wide field of view but can also work in tandem with additional readers for an even wider field of view. Master stations are capable of summarising data from slave stations, allowing users to control multiple readers as if they were a single code reader. Because the host is not required to control multiple readers individually, programming work can be greatly reduced.
⇒ Data edit function – Customisable reading data output formatting
Thanks to the SR-2000 Series’ ability to offer customisable data output formats, programming corrections on the host side (PC, PLC, etc.) are not required, resulting in shorter data processing.
Download our guide
Send download link to:
What is a sensor – Guide
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Fanless rugged embedded computer – Low-profile chassis, reduces its height
Nuvo-5002LP/5006LP is the low-profile version of Nuvo-5000 family. It features a low-profile chassis, which reduces its height to 77 mm, and remains extraordinary 25°C to 70°C operating temperature. For those demanding varied computing power, Nuvo-5002LP/5006LP supports socket-type CPU for flexible CPU installation. You can choose Intel® 6th Gen Core™ i7/i5/i3, from 35W to 65W TDP, according to your performance consideration and operating environment.
A ruggedized application platform with optional MezIO™ module
Nuvo-5002LP/5006LP fanless embedded computer inherits comprehensive I/O functions, such as GbE, USB 3.1 Gen1/ USB 2.0, COM and VGA/DVI/DP, from Nuvo-5000E/P. It also incorporates Neousys’ MezIO™ interface for further I/O expansion. By installing optional MezIO™ module, Nuvo-5002LP/5006LP turns immediately from a typical embedded controller to a ruggedized application platform including 11x COM ports, 32 DIO channels, ignition power control, or your customized application-specific I/O.
Feature Nuvo-5002LP/5006LP – Fanless rugged embedded computer
⇒ Intel® 6th Gen Core™ i7/i5/i3 35W/65W socket-type CPU
⇒ MezIO™ interface for easy function expansion
⇒ Rugged, wide temperature range from -25°C to 70°C fanless operation
⇒ Up to 6x GigE ports, supporting 9.5 KB jumbo frame
⇒ Up to 32 GB, DDR4-2133 SODIMM
⇒ One hot-swappable 2.5” HDD/SSD and one fixed 2.5” HDD/SSD, supporting RAID 0/1
⇒ Accommodates two 2.5″ SATA HDD/SSD with RAID 0/1
⇒VGA/DVI/DP triple independent display, supporting 4K2K
⇒77 mm low-profile design
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Rugged cellular router equipped with a dual-band WiFi interface
RailBox LTE is a rugged cellular router equipped with a dual-band WiFi interface (2.4 / 5 GHz), a multiconstellation GNSS interface (GPS, GLONASS …), 2 Ethernet ports 10/100/1000/2500, one alarm output and one digital input. RailBox LTE is designed to be mounted on trains, subways, trams or any other mobile equipment in harsh environment.
Provides a secure backup connection for maintenance applications
RailBox LTE uses dual-SIM 4G/5G LTE and WiFi 802.11n/ac/ax MIMO radios to guarantee broadband data transfers in motion or stationary (station or depot). Its cellular interface provides a secure backup connection for maintenance applications along the journey; its WiFi interface adds high speed communications wherever the WiFi coverage is available (depot, station, covered sections along the journey …).
C-KEY for quick backup/restore
Definitely designed for mobility, RailBox LTE complies with all EN50155 standards and meets the most stringent environmental requirements: shocks and vibrations proof, IP66, operating temperature up to -40°C/+70°C. RailBox LTE features a dual insulated power supply, M12 hardened connectors and C-KEY for quick backup/restore of the product configuration.
Digital I/O can be used to remotely control a device thanks to a relay and to read the logic state of an input signal.
This product is also available in rugged dual 802.11ac/ax WiFi access point version
Feature:
⇒ 2G/3G/4G/5G LTE router (dual SIM)
⇒ WiFi 5 or WiFi 6 interface
⇒ Multi-constellation GNSS (GPS, GLONASS…)
⇒ Advanced security, VPN, firewall…
⇒ Rugged device : dual insulated redundant input (EN50155 nominal), shocks & vibrations proof, IP66
⇒ Operating System : WaveOS
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Acksys – RailBox LTE
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Closely collaborates with its extensive network of partners and suppliers.
As a global leader in IoT/Embedded Computing Technology, Recab & Kontron closely collaborates with its extensive network of partners and suppliers. We offers individual and secure solutions in the areas of Internet of Things (IoT) and Industry 4.0 through a combined portfolio of hardware, software and services.
Standard and customized products
With its standard and customized products based on highly reliable state-of-the-art technologies, We provides highly efficient and flexible automation platforms. As a result, customers benefit from accelerated time-to-market, lower total cost of ownership, extended product lifecycles and the best fully integrated applications. Below you see a selection of products for production & smart automation
D3714-V/R mSTX Industrial Series – Industrial Motherboard
The industrial motherboard D3714-V/R mSTX supports the AMD Ryzen™ Embedded V1000 and R1000 series processors with integrated AMD Radeon™ Vega Graphics and can be used in applications with high graphical requirements like:
⇒ Casino gaming
⇒ Medical displays
⇒ Thin clients
⇒ Ultra small industrial PCs
Feature:
⇒ AMD Radeon™ Vega Graphics (within SoC)
⇒ Up to 3x DisplayPort V1.4 plus HDMI V2.0b
⇒ Dual Channel LVDS (24 Bit) and eDP V1.3 (4 k) onboard
⇒ Designed for Fanless Operation
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron – Industrial motherboard D3714-V/R mSTX
SMARTCASE™ S511 – Chassis kit solution for D3714-V/R MSTX
A new tiny chassis designed for the industrial motherboard D3714-R mSTX supporting the AMD Ryzen™ Embedded R1000 processor series. With a housing volume of only 0.87 litres but lots of connectivity and power inside the S511 fits perfectly for e.g. digital signage and many other applications. The SMARTCASE™ S511 can be used in horizontal and vertical mode.
Feature:
⇒ Industrial chassis for enhanced operating temperature range
⇒ Ultra-Compact Design
⇒ 36 x 147 x 165 mm
⇒ Front & Rear USB
⇒ Horizontal or Vertical Operation
⇒ VESA- and Wall Mount Option
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron – SMARTCASE™ S511 Chassis Kit Solution
KISS 2U Scalable Rackmount System for challenging or noise sensitive environments.
The rackmount servers are designed and tested for challenging environments and are therefore the perfect fi t for high temperature and mechanical stress conditions. Industrial grade design, in combination with high processing performance allows industrial applications requiring high performance and storage capabilities.
Feature:
⇒ Industrial grade for challenging environments – robust, reliable and sustainable
⇒ High processing capability: up to 8th Gen Intel® Core™ i7/i5/i3 or Intel® Xeon®-E
⇒ Modular concept allows easy customization
⇒ Low noise design
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron – KISS 2U Scalable Rackmount System
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Industrial Raspberry Pi
Based on the Raspberry Pi Compute Module, we can present a solution tailored to your requirements, equipped with numerous industrial interfaces and functions. Touch displays can be connected directly via DSI or Micro-HDMI, and 24 V power supply facilitates integration with industry applications.
These features give you a tool for rapid and secure development and testing of your applications. As an optional service, we can adapt the evaluation board to your specific needs. Where required, we develop an entirely new board to achieve minimum serial production costs and optimal dimensions. Make the BL Pi-Tron CM3+ baseboard your companion in the industrial Raspberry Pi world!
Applications:
⇒ Human-machine interface
⇒ Industrial communication
⇒ M2M (machine-to-machine)
⇒ Building automation
⇒ POS displays
⇒ Infotainment/Entertainment
⇒ Portable systems
Feature:
⇒ Broadcom BCM 2837B0 4x Arm® Cortex-A53 @1.2 GHz
⇒ 3D Video Engine, 1 GB LPDDR2-RAM
⇒ Suitable for CODESYS SoftPLC
⇒ Highly scalable computing power
⇒ Standard technology
⇒ Possible customization
⇒ Rapid migration from Raspberry Pi prototype to series product
⇒ High-performance interfaces for harsh industrial applications
⇒ 24 V power supply
Your Benefits:
⇒ Industrial interfaces
⇒ Fast prototype construction
⇒ Adaptable on demand (cutting, form factor, housing)
⇒ Large community through open source software
⇒ Short time to market
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron – INDUSTRIAL Raspberry Pi – BL Pi-Tron CM3+
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Challenges of Robot System Design
Whether industrial robots or autonomous robots – vision, AI, and sensor fusion with functional safety are key technologies to enable these robot systems. With the rising challenges of developing robotic solutions safer, more sustainable, and more intelligent, robot builders and OEM customers are looking for industrial computing hardware that can perform in harsh environments. This hardware not only handles critical conditions such as vibration, humidity, and temperature but also needs to meet requirements regarding computing power, real-time computing & communication, thermal management, and safety regulations. These are all important factors for reliable and maintainable robot control systems
Shorten Time-to-Market with FuSa-certifiable HW
Functional safety is critical for many modern robotic applications and will become even more important when innovations in robotics that deliver optimized functions are also enabling close collaboration between humans and robots in the same workspace. When a robot fails, there is a risk to the surrounding workers, product safety and public safety. Therefore, mitigating safety risks under these conditions will become a fundamental requirement that is considered an integral part of robot system design. congatec offers functional safety- certifiable computer modules to help robot builders and OEM customers shorten the time to market. Computer-on-Modules can be utilized as an application-ready building block including relevant software components such as bootloader, hypervisor and BSP that is already certifiable for functional safety and receive the support and documentation from congatec to speed up the development cycle.
Easy safety management with hypervisor capabilities
Hypervisor support from Real-Time Systems makes the embedded computer technologies from congatec even more attractive to robot builders and OEM customers. It allows multiple operating systems to be installed on a multicore x86 platform without impacting real-time capability. An embedded hypervisor allows systems to run separate and isolated OSs, such as Linux, Windows, and QNX, on a single multicore x86 processor. This is important for ensuring safe mixed-criticality workloads when designing the system with functional safety to separate safety-critical tasks from other tasks and allows more computing power to be executed at a higher level of efficiency on a single piece of hardware with low latency.
Simply AI and 3D machine vision development
While sensor fusion helps robots to be more accurate, leveraging artificial intelligence (AI) can help make robots intelligent. Incorporating AI into robot systems can help enable robots to intelligently perceive, make decisions and perform tasks. A robot with AI capabilities can intelligently detect the object and its position, to take action accordingly. congatec’s COM Express modules provide the demanded performance scalability from Intel’s low-power to high-end processors. Combining Intel’s heterogeneous processor technology with Intel’s OpenVINO™ AI toolkit offer deep-learning models, device portability, and higher inferencing performance with fewer code changes to accelerate AI application development.
Recommended products from congatec:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Web panel designed as long-term available devices
The Web Panels are delivered with a smart “QIWI” software toolkit with a performance-optimized HTML-5 browser together with numerous sophisticated features for the specific needs of industrial users.
For a flexible choice of performance levels we offer Arm® based i.MX6 single or dual core and i.MX8M Mini Quad Core as well as Intel Atom® based dual or quad core processors.
The Web Panels have been designed as long-term available devices (> 10 years) and can also be customized and optimized to individual requirements.
Feature for WP web panel:
⇒ Display sizes: 7”, 10.1” and 15.6” versions, capacitive multi-touch
⇒ IP65 aluminum front bezel, optional stainless steel
⇒ High performance up to Intel Atom® Quad Core™ or Arm® i.MX8M Mini Quad Core
⇒ Chromium based HTML-5 browser or MicroBrowser
⇒ QIWI software toolkit for better performance and easy configuration
Download dataheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron – WP WEB PANEL
About Kontron:
Kontron is a global leader in IoT/Embedded Computing Technology (ECT). Kontron offers individual solutions in the areas of Internet of Things (IoT) and Industry 4.0 through a combined portfolio of hardware, software and services. With its standard and customized products based on highly reliable state-of-the-art technologies, Kontron provides secure and innovative applications for a wide variety of industries. As a result, customers benefit from accelerated time-to-market, lower total cost of ownership, extended product lifecycles and the best fully integrated applications.
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Background to Recab Solution for case in Military Surveillance
The products is primarily used in border control and long-range surveillance. They are used all over the world so the system must work during all climates and weather conditions. This makes the demands on a camera very high and difficult.
Challenge for the Team players at Recab
⇒ The light conditions are very challenging, from direct sunlight in to the camera to the dark of the middle of the night.
⇒ Customer needed an easy way to calibrate the system to get the optical center in the lens and camera to line up correctly.
⇒ A way to keep the option of long exposure times, that is larger than 1s.
⇒ Easy integration with current set up.
Solution for the customer
By choosing a camera from Imperx with a Sony IMX265 sensor we got better resolution and light sensitivity than the previous camera. With HD-SDI interface it was the same as before, so ease of integration was accomplished. The camera also works in a wide temperature range -30 to +75 degrees witch makes the implementation easier for the customer.
The calibration was fixed by an mechanical change to the camera so that the front plate holding the lens and the rest of the camera was separated and adjustable. This saved the customer a lot of time in the calibration step.
A firmware change allowed for longer exposure times than the sensor normally supports.
Benefits for the customer
⇒ Simple Out of the box integration with customers system.
⇒ Time saved in the calibration step.
⇒ Full HD resolution without loss of frame rate and better light sensitivity gives the operator a better image.
Military Cameras from Imperx
IMPERX manufactures high performance cameras for industrial, military, medical and municipal applications. Combining extensive, easy-use features with the best CCD and CMOS sensors, IMPERX cameras are available in resolutions from VGA to 47 Megapixels. Designed to perform to the highest standards in harsh environments, the extended operating temperature is -40˚C to +85˚C with a MTBF > 660,000 hours @ 40˚C. IMPERX camera outputs: GigE Vision®, PoE, Camera Link®, CoaXPress and HD-SDI.
We can offert Military Cameras with High Speed, Ruggedized Cameras for Military, Surveillance & Defense Applications within the area:
⇒ Military Jets
⇒ Military Nigh Fighters
⇒ Naval Periscope
⇒ Military Surveillance
⇒ Military Drone & Carrier
⇒ Military Airplane
⇒ Military Tank & Crew
Link to Recab Defence & Avionic selection with more solutions
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Computers with Automation and IoT solutions
Depending on the complexity of the application, a wide variety of processor variants, diverse interfaces, expansion modules and software solutions are available. Robust design makes the product versatile and particularly suitable for use in industrial applications. The scope of services is complemented by modern and extremely powerful CODESYS Soft PLC development tools. They support the efficient and fast implementation of sophisticated automation solutions.
AL PI-TRON CM3+ & AL PI-TRON CM4 – Rasbian Linus hat-rail computer
The Internet of Things (IoT) demands ever smaller but nevertheless high-performing controller solutions as standard. They must also provide a wide array of industrial-use interfaces to offer expansion options for various applications.
One special feature of our Automation Line Pi-Tron is that we make the Raspberry Pi processor variants Compute Module CM3+ and CM4 available in a chassis suited for hat-rail mounting. The Pi-Tron CM4 features an HDMI slot for standard display devices as well as LVDS display connectivity via an adapter board. 24 V power supply ensures easy integration with industrial applications. Further inputs and outputs can be added easily via multifunctional I/O modules. Communication is via CAN interface.
Feature:
⇒ Compact Box-PC
⇒ Raspbian Linux operating system
⇒ Wide range of interfaces
⇒ Robust chassis
⇒ Flexible top-hat rail assembly
Customer benefits:
⇒Small, compact design
⇒ Optional expansion via multifunctional I/O module
⇒ Excellent price/performance ratio
⇒ Large community providing software examples and fully translated program packages
Applications:
⇒ Automation
⇒ IoT Gateways
⇒ Communication
⇒Edge Computing
⇒ Mechanical Engineering
⇒ M2M (machine-to-machine) Gateway
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron AL PI-TRON CM3+ & AL PI-TRON CM4
AL i.MX8M Mini Design with Automation and IoT solutions in mind
The Automation Line AL i.MX8M Mini, based on Arm® Cortex® A53 and Arm® Cortex® M4, is another addition to our Linux computer portfolio for DIN rails. The compact design features a wide range of communication interfaces as well as a modern HDMI interface for display use. The robust chassis is specially designed with automation and IoT solutions in mind.
AL i.MX8M Mini is predestined for sophisticated control tasks and as an intelligent gateway for IOT applications. The Automation Line (AL) can easily be expanded via multifunctional I/O modules. The I/O assemblies can be controlled via CAN Bus, and up to 16 modules can be connected. Where required, individual I/O modules can be customized to meet your specific requirements.
Feature:
⇒ Compact Box-PC
⇒ Embedded Linux operating system
⇒ Wide range of interfaces
⇒ Robust chassis
Customer benefits:
⇒ Small, compact design
⇒ Flexible top-hat rail assembly
⇒ Optional expansion via multifunctional
⇒ I/O module
⇒ Excellent price/performance ratio
Applications:
⇒ Automation
⇒ IoT Gateways
⇒ Edge Computing
⇒ Mechanical Engineering
⇒ Control
⇒ Communication
⇒ Visualization
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron AL i.MX8M Mini
KBox A-150-APL DIN RAIL Embedded Box PC
Developed specifically for control cabinet applications the KBox A-150-APL offers flexible DIN Rail mounting positions even when space is limited. The fanless design ensures a significantly prolonged lifespan and high system availability.
The KBox A-150-APL offers high processor performance at low power dissipation by Intel® Pentium® Quad Core N4200, Celeron® Quad Core J3455 or Intel Atom® E39xx processors (Dual and Quad Core Processor option). The KBox A-150-APL is Microsoft Azure Certified, which makes it perfectly suited for working with Microsoft Azure IoT services.
Feature:
⇒ Processor: Intel® Pentium® Quad Core™ N4200 1.1 GHz /2.5 GHz (Burst)
⇒ Main Memory: Up to 16 GB Max. with 2x DDR3L 1867 SODIMM
⇒ Audio: Optional
⇒ Interface: 4x USB 3.0, 2x LAN (GbE), 1x HDMI, 1x DP, 2x COM ( RS 232, RS422, RS485, BIOS configurable), 2x COM (RS232 option)
⇒ Expansion Slots: 1x mPCIe
⇒ Operating System: Windows 10 IoT Enterprise (64 bit)
⇒ Linux Ubuntu: 16.xx (64 bit)
⇒ BIOS: AMI uEFI BIOS, Aptio V5
⇒ Mounting: DIN Rail
⇒ Weight: Approx. ~1 kg (~2.2 lbs.)
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Kontron KBox A-150-APL DIN RAIL Industrial Computer Platform for Control & Process Optimization
Link to Recab’s range of Kontron products & solutions
Link to Kontron
KBox A-151-TGL – Industrial computer for data intensive IoT Edge & AI applications:
Based on the 11th generation Intel® Core™ or Celeron® processors and offers sufficient computing performance even for demanding IoT edge or AI applications. As a special feature, the system has an expansion slot on the front (I/O Door), which can be used to expand the KBox A-151-TGL with additional functionalities such as fieldbuses, interfaces such as graphics, serial or digital I/Os, and Ethernet interfaces. Optionally, the system can also be expanded to include 4G/5G or even WiFi 6 connectivity.
Feature:
⇒ Based on 11th Generation Intel® Core™ U-Series
⇒ Broad range of interfaces with WIFI and LTE option
⇒ Flexible system expansion via I/O door
⇒ Passive cooling concept, option for extended temperature range
Download datasheet
Send download link to:
Kontron KBox A-151-TGL – Industrial Computer
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Rugged 3U VPX Plug in Card (PIC)
Designed in alignment with the SOSA ™ Technical Standard, PR A11/61d-RCR provides resilient PNT data for sensor based solutions that are used in Electronic Warfare and Intelligence, Surveillance and Reconnaissance applications. As a key differentiator, PR A11/61d-RCR is ITAR free and is designed and built in the UK utilising technology licensed from Racelogic, another UK company specialising in positioning data.
Feature:
⇒Integrated multi-constellation, multi-frequency GNSS module with interference and jamming mitigation
⇒ Chip Scale Atomic Clock (CSAC) and Inertial Measurement Unit (IMU) for assured Position Navigation and Timing
⇒ Differential radial clock distribution
⇒ Coaxial Antenna and Timing signals in P2 aperture
Supported for backwards compatibility with older VPX systems.In normal operation, PR A11/61d-RCR sources highly accurate PNT data from a built in GNSS receiver and uses this to discipline a Chip Scale Atomic Clock (CSAC).
This, in turn, feeds radial clock signals to the signal processing plug in cards that make up a VPX based sensor subsystem. In periods of GNSS denial or jamming, accurate PNT data continues to be provided by utilizing signals from a built in Inertial Measurement Unit and sophisticated Kalman filtering techniques.
The timing slot on most commercially available backplanes supports one or two 10GBASE-KR pipes and PR A11/61d-RCR is controlled using one or other of these pipes. Bussed clock signals are also supported for backwards compatibility with older VPX systems.
Download datasheet (Available for Sweden, Norway & Denmark)
Send download link to:
Link to Recab’s articles and products with Concurrent
Link To Concurrent
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Edge solutions – Industry 4.0 the industrial revolution
In the 1800s, the first industrial revolution saw manual labor replaced by steam power. Then, at the start of the 20th century, electricity changed the industrial landscape again. In the second half of the 20th century, the third industrial revolution placed computing at the center of everything. Industry 4.0 is all about connectivity.
-Our computers have become so sophisticated, they can learn to communicate – not only with each other, but with machines, factories and entire supply chains. In this interconnected world, it is possible for manufacturers to streamline operations and optimize processes, delivering huge cost-savings and efficiencies.
Let us present a selection from our partner Aaeon with AI@Edge solutions:
BOXER-8233AITX2 AI@Edge Compact Fanless Embedded BOX PC
with NVIDIA® Jetson™ TX2 NX
NX is powered by the dual-core NVIDIA Denver 2 64-bit CPU and quad-core Arm® Cortex®-A57 MPCore processor complex, offering 256 Cuda® Cores and 4GB of onboard LPDD4 memory. In total, this offers AI processing speeds up to 1.33 TFLOPS
Feature:
⇒ NVIDIA® Jetson™ TX2 NX
⇒ 4GB LPDDR4
⇒ Multi-storage option: 16GB eMMC / MicroSD slot / mSATA slot / 2.5 drive bay
⇒ GbE PoE/PSE LAN x 2
⇒ HDMI Input x 1 & HDMI Output x 1
⇒ Digital I/O 13-channel
⇒ Expansion support for WiFi/LTE
Download Datasheet
Send download link to:
Aaeon BOXER-8233AI – AI@Edge Compact Fanless Embedded BOX PC
BOXER-8240AI AI@Edge Fanless Embedded BOX PC with AGX Xavier
The heart of the BOXER-8240AI is the innovative and powerful NVIDIA Jetson AGX Xavier; featuring the Volta GPU which packs an astonishing 512 CUDA cores and 64 Tensor cores, offering AI processing speeds up to 32 TOPS.
Feature:
⇒ 512-core Volta GPU with Tensor Cores
⇒ Support RJ-45 x 4 for PoE (802.11af, total 60W)
⇒ Support DB-9 x 1 for RS-232/422/485, CANBUS x 1
⇒ Support 40-pin header, Mic in and Line out
⇒ Support M.2 E key, M key and SATA storage
Download Datasheet
Send download link to:
Aaeon BOXER-8240AI – AI@Edge Fanless Embedded Box PC
BOXER-8250AI AI@Edge Fanless Embedded Box PC with NVIDIA Jetson Xavier NX,
5 GbE LAN Ports
NVIDIA Jetson Xavier NX SoC features a six-core 64-bit ARM processor, boasting 384 CUDA® cores, 48 Tensor Cores, and two NVDIA engines capable of running multiple neural networks in parallel. Built to bring dedicated AI processing to the edge.
Feature:
⇒ NVIDIA® Jetson Xavier™ NX
⇒ 8GB LPDDR4
⇒ Multi-storage option: 16GB eMMC / MicroSD slot / 2.5” drive bay
⇒ Support Operating Temperature -25°C ~ 70°C
⇒ GbE LAN x 5
⇒ USB 3.2 Gen 1 x 4
⇒ 10~24Vdc Power input
Download Datasheet
Send download link to:
AAEON BOXER-8250AI AI@Edge Fanless Embedded Box PC
BOXER-8221AI AI@Edge Compact Fanless Embedded BOX PC with NVIDIA Jetson Nano
The Jetson Nano SoC combines the quad-core ARM® Cortex®-A57 MPCore processor with NVIDIA Maxwell™ GPU architecture featuring 128 NVIDIA CUDA® cores. This innovative design allows processing speeds up to 472 GFLOPs and is capable of operating multiple neural networks or processing several high-resolution images at the same time. The NVIDIA Jetson Nano also provides the BOXER-8221AI with 4GB RAM and 16 GB eMMC storage.
Feature:
⇒ NVIDIA Jetson nano
⇒ Quad core ARM A57 Processor
⇒ 4GB LPDDR4 + 16GB Micro-SD or eMMC
⇒ LAN x 1 + RS-232 x 2
⇒ 12Vdc Power input
Download datasheet
Send download link to:
AAEON – BOXER-8221AI
Recab engineering team develops for Your future needs
Recab engineering team has through years of experience, with developing products & solutions, established a successful & effective organization.
Our engineers work closely with our customers to create exceptional products that meet the requirements & demands for the application.
Contact us for discussions, solutions and products.
Link to Aaeon & Edge solutions
Link to Recab Engineering team
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Printec Keyboards – we tailor to your needs
Keyboards, whether they are made of stainless steel or plastic, both as a built-in version and in table or wall housings. We complement our compact and flat silicone keyboards, which are particularly suitable for installation in consoles, regardless of whether they are horizontal or vertical.
We tailor each of our keyboards to your request with a suitable country variant, different connection options and much more. And if none of the products we offer match the requirements required, we are happy to work with our customers to develop an individual, special solution.
Let us present a selection of Printec keyboards:
Features for 86TES
⇒ Predestined for public surroundings (vandalism risk), industrial extreme surroundings
⇒ Dimensions of 334 x 150 x 32 mm
⇒ Keycaps and front panel made of stainless steel
⇒ Almost resistant to the effects of violence
⇒ Durability > 10 million ops.
⇒ Operation temperature 0°C – +60°C (optional -20°C – +60°C)
⇒ Protection IP65, IK09
Download Datasheet
Send download link to:
Printec Keyboards 86T ES – public surroundings (vandalism risk), industrial extreme surroundings
Features 82TES16 TB25
⇒ Predestined for public surroundings (vandalism risk), industrial extreme surroundings
⇒ Dimensions of 395 x 130 x 42 mm
⇒ Almost resistant to the effects of violence
⇒ Durability > 10 million ops.
⇒ Operation temperature 0°C – +60°C (optional -20°C – +60°C)
⇒ Protection IP65, IK09
Download Datasheet
Send download link to:
Printec Keyboard 82T ES16 TB25 – public surroundings (vandalism risk), industrial extreme surroundings
Features 65T-ES ATK
⇒ Predestined for public surroundings (vandalism risk), industrial extreme surroundings
⇒ Dimensions of 303 x 112 x 19 mm
⇒ Keycaps and front panel made of stainless steel
⇒ Almost resistant to the effects of violence
⇒ Durability > 1 million ops.
⇒ Operation temperature 0°C – +60°C (optional -20°C – +60°C)
⇒ Protection IP65
Download Datasheet
Send download link to:
Printec Keyboard 65T ES ATK – public surroundings (vandalism risk), industrial extreme surroundings
Features DS105S TP
⇒ Predestined for industrial, military, and maritime applications in the harshest environments
⇒ Dimensions of 309 x 127 x 16 mm
⇒ Durability > 1 million ops.
⇒ Operation temperature -30°C – +60°C
⇒ Protection IP68
⇒ EMC Compliant acc. to DIN EN IEC 61000-6-2 and 61000-6-4
Download Datasheet
Send download link to:
Printec Keyboard DS105S TP – industrial, military and maritime
Features DS85S
⇒ Predestined for industrial, military, and maritime applications in the harshest environments
⇒ Dimensions of 238 x 127 x 16 mm
⇒ Durability > 1 million ops.
⇒ Operation temperature -30°C – +60°C
⇒ Protection class IP68
⇒ EMC Compliant acc. to DIN EN IEC 61000-6-2 and 61000-6-4
⇒ Climate test acc. to MIL-STD-810H 507.6 and DIN EN IEC 60068-2-1
Download Datasheet
Send download link to:
Printec Keyboard DS85S – industrial, military and maritime
Customized keyboards
Are you looking for an individual input solution for one of your products? Do you have high demands on design, quality and functionality? Do you need a keyboard that does not meet standards?
No matter whether membrane keyboard, customized keyboards made of plastic or metal, silicone keyboard, capacitive key fields or customer-specific touch screens. We can offer you a perfectly tailored product for every requirement. We bundle our expertise in the field of input systems with the knowledge of our selected production and development partners in Europe and Asia.
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Stainless Steel Panel PC – Why Stainless Steel?
Sanitation is a serious issue of food/beverage industry so it is necessary to do the intensive cleaning to maintain the hygienic environment. Stainless steel is the first option in food and beverage manufacturing industry due to its leanability, high corrosion resistance, and germ-resistant which can prevent the food/beverage from bacterial poisoning and will not damage people’s health.
Recab offers Panel PC and Displays for many situations. Some 7 inch touch with a arm processor for very tough environment, others might have a Maritime certification for use at sea. Units can be openframe for You to integrate in Your application, or it might have a stainless steel frame with high IP class. Of course, we have the option of versatile mounting for the Stainless Steel Panel PC:s
Let us present a model of ViTAM – For harsh environments:
Download datasheet:
Send download link to:
Below you can also find some other popular models from Aplex products series:
Download datasheet:
Send download link to:
Download datasheet:
Send download link to:
We have products, solutions & support for your daily business, find a selection of our offer below or read more about our Engineering capabilities and our successful applications.
The Recab engineering team has through years of experience with developing products established a successful and effective organization. Our engineers work closely with our customers to create exceptional products that meet the requirements and demands for the application.
Read or guide: Industrial PC – Rugged solutions that are built to last
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
OpEdge-8D Industrial Edge Gateway Device, make operational data more useful.
Bring edge computing capabilities into your local automation infrastructure with an industrial-grade device capable of running applications that make operational data more useful. Secure remote access functionality offers a safe bridge to the cloud, allowing the device to leverage advanced orchestration capabilities that simplify installation and management.
⇒ Bridge the IT-OT divide with OpEdge™ hardware that leverages the latest IT technologies to provide a secure, reliable and scalable solution for connecting IT and OT systems.
⇒ Obtain useful insights by collecting and processing data through applications deployed on the device edge runtime.
⇒ Securely manage deployments at scale with the cloud-hosted Belden Horizon™ console, which provides native device management, application orchestration and secure remote access functionality.
Markets
The OpEdge-8D is suitable for use in any industrial setting including manufacturing, energy, transportation and machine building
Feature:
⇒ Industrial-grade design for DIN rail mounting with convection-cooled metal housing
⇒ CPU: Intel Atom E3950 @1.6 GHz
⇒ Memory: DDR3L 8GB
⇒ Storage: 64GB SSD
⇒Ethernet ports: 5 x GbE RJ45 ports + 2 x GbE SFP ports
⇒ USB/Serial Ports: 2 x USB 3.0 ports + 2 x DB9 ports for RS-232 protocols
⇒ Operating temperature range: -40°C to +70°C
⇒ Edge runtime environment for containers and virtual machines
⇒ Secure remote access for a protected, remote connection to the cloud
⇒ Integrated with the cloud-based Belden Horizon™ console for device management and application orchestration
Industrial Edge Gateway Device, bridge the IT-OT divide by empowering infrastructures
Hirschmann’s OpEdge-8D gateway helps companies bridge the IT-OT divide by empowering their industrial infrastructures with a device that will help them achieve their Industrial Internet of Things (IIoT) goals.
Benefits
⇒ With an increase in connected devices and the rise of IIoT, companies have an excess of available data. But many are ill-equipped to manage large amounts of data and analyze it to create valuable, actionable insights.
⇒ The OpEdge-8D helps overcome this challenge with data pre-processing power capable of running user applications to make data useful. The device enables these applications to be run locally, and then makes the resulting insights more easily available to engineers in the field.
⇒ The device provides a runtime edge environment for operating user applications that integrates into the Belden Horizon™ cloud-based device management and application orchestration platform. This enables users to easily implement, install and integrate with various industrial applications – no matter the vendor – providing meaningful outcomes locally on the network, including increased efficiency and maximized uptime.
Plus, with its secure remote access capability, users can ensure their link to the cloud is protected from rising and sophisticated cybersecurity concerns.
Link to Recab’s range of network solution
Link to Hirschmann
Send download link to:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Industrial motherboard MANO321
The MANO321 is powered by the low power consumption Intel® Celeron® processor J6412 (codename: Elkhart Lake); it’s equipped with two 260-pin DDR4-3200/2666/2400 SO-DIMM slots for up to 32G of system memory. Its low-profile design lowers the height of the board by half of the standard Mini-ITX form factor, making it more flexible for various IoT applications.
5G connection
To enable 5G connection, it has a SIM card slot and an M.2 Key B slot with USB 3.1 interface, which allows adding a 3042/3052 5G module to gain the connection. For display-related applications, the MANO321 supports triple-view with one HDMI 1.4b, one VGA, and one LVDS. Besides, it has HD Codec audio. In terms of expansion interfaces, the industrial motherboard provides one PCI Express Mini Card slot and one PCIe x4 slot with PCIe x2 signal.
Features MANO321:
Kenny Lin, the product manager of the Product Planning Division at Axiomtek:
“Our MANO mini-ITX motherboards are widely deployed in industrial control applications and can be used for digital signage applications in retail and public transportation venues. The fanless MANO321 offers rich features, high computing power, slim-size form factor and graphics-rich performance.
With 5G capability and its low latency, the MANO321 can make the IoT truly feasible in the manufacturing industry. In terms of space, its low-profile design is an excellent choice for limited space and installation flexibility,”
Provides one mSATA and one SDHX slot
To strengthen the versatility, the MANO321 features rich I/O options including one SATA600 connector, two Gigabit Ethernet with support of Wake-on-LAN and Boot ROM, four USB 3.1, four USB 2.0, six COM, 8-CH DIO, HDMI, VGA, LVDS, and one SMBus pin header, which make the board ready for the industrial environment. If users require more storage space, it also provides one mSATA and one SDHX slot. The M.2 Key B slot can also be compatible with SATA interface for 2242 SSD. It also supports Linux and Windows operating systems. Additionally, the MANO321 supports Trusted Platform Module (TPM) 2.0 and a watchdog timer for optimal security.
Download datasheet
Send download link to:
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
Background to Recab Solution
A Swedish metal manufacturer had problems with reading DPM (Direct Part Marking) codes for track and trace applications. The product goes thru several stages like heating and panting etc. The code must be readable thru the whole process.
Challenge for the Team Players at Recab
Due to variation in light and reflections the code reader customer used was not able to read such codes. The time and waste of material on misreading becomes very costly and thus not profitable.
Solution for the customer
Recab went out at customer site and set up our code readers with the smart artificial intelligence software. The system then optimizes the settings to be able to read the code. The code could then be read with accuracy. The product that solve the problem is Keyence SR-1000 and SR-2000 series – a fixed mount readers with an easy handling for the customer.
Facts Keyence SR-Series for 1D & 2D reading
The Keyence SR-Series is an automatic focus code reader. Reading the most difficult 1D and 2D codes is made simple through the introduction of new features including automatic tuning, auto-focus, and built-in polarization.
Best-in-class performance is paired with built-in I/O and field network functionality, including EtherNet/IP and Profinet, to allow for easy integration with any system. The SR-1000 is available as a standard type and a wide-field type (SR-1000W). Download datasheet
Send download link to:
Benefits for the customer
The Customer get a reliable system to read DPM codes for track and trace. Customer also use this in many processes in the factory, where different forms of code reading are required to ensure the integrity of the process, mainly on metal objects. he codes could then be sent to remote quality system for logging. The codes are readable during all manufacturing processes.
Extra Facts – What is Barcode/Two-dimensional Code Verification?
“Barcode verification” refers to checking the marking quality of CODE39, CODE128, and EAN barcodes. Barcodes are used in a variety of fields such as FA, distribution, food, wholesale, and medical products.
“Two-dimensional code verification” refers to checking the marking quality of DataMatrix symbols and QR code symbols. Two-dimensional codes have spread to a wide variety of fields, and there are many cases in which the same two-dimensional code is read at multiple work sites.
Examples include between automotive parts suppliers and automobile manufacturers, between medicine manufacturers and pharmacies, and between smartphone module manufacturers and assembly manufacturers.
Two-dimensional codes are marked on key parts at the part or module manufacturer and are read at the assembly manufacturer. This makes it possible to obtain information such as the product characteristics and serial number, which is put to use in maintaining production and quality.Barcodes or two-dimensional codes that are difficult to read hinder productivity. Various code verification standards have been developed as quantitative guidelines aimed at eliminating this problem.
Link to Recab’s range of Keyence (Available in Sweden and Norway)
Link to Keyence
Even in an organization where IT and OT people work well together, inevitably, it will come up:
Who is in charge in situation x? Does IT or OT have the final word on equipment and operations in the DMZ?
Who specs network-wide Ethernet equipment?
See experience – based best practices.
Mech-Eye 3D camera “sees” target objects, Mech-Vision “understands” depth information of objects, then how to ensure flexible and reliable robotic operations without collisions? That’s where Mech-Viz comes to play – let us present some examples.
With the mature AI+3D solutions, You can create demanding robotic systems with 3D cameras that help you reduce errors and secure your production from day 1.
2D & 3D Laser profiler reaches over 720mm (28″)
The maximum laser line width reaches over 720mm (28″), and multiple can be paired together to scan even larger targets. Programming for these high-performance sensors is completed in three simple steps, making accurate in line 3D measurement accessible for users of any experience level.
⇒ Capture the shape of targets in exceptional detail with the new standard in high-resolution measurement, 3200 points/profile.
⇒ Capture stable profiles from any target, regardless of colour, material, or shape.
⇒ Set up in 3 easy steps – Measurement and inspection settings can be configured in three easy steps that any user can complete. Designed to handle a wide-range of applications, from profile measurement to 3D inspection.
2D Measurement
3D Measurement
Highlights:
Cylindrical lens – Parallel light is emitted using a cylindrical lens designed to prevent the reflected light from scattering across the surface of the target. This ensures reliable reflections from any shape or surface.
Large-aperture receiver lens – In addition to the unique optical design, a large-aperture light-receiving lens that covers three times the area of the conventional lens is installed to deliver the increased amount of light received.
High-resolution CMOS – This newly developed CMOS enables high-resolution measurement using 3200 points/profile, while delivering improved imaging capability on targets with varying reflectivity.
Examples 2D Measurement:
Car door flush and gap – Control flush and gap at the micron level.
By mounting the sensor on a
*multi-axial robot, inspections can be performed inline.
Examples 3D Measurement:
Brake rotor porosity. Using 3D images, it’s possible to detect porosity in rough surfaces. High resolution profiles enable stable detection of even the smallest dents.
Examples: Tire shape / DOT code inspection
With improved X-axis and Z-axis precision, it’s possible to holder tighter tolerances over a wider inspection area. This significantly expands the types of applications that can use 3D measurement.
Maximising resolution and target detection
To improve the resolution of the sensor, the number of pixels on the CMOS needs to be increased, which can be accomplished by making each pixel smaller. But smaller pixels can result in insufficient light to create an accurate profile of some target shapes or surfaces. For the LJ-X series, we’ve implemented new technology to create a laser profiler capable of high resolution measurement on any target.
Download datasheet
